Adapter 2 1/2 inch IT to G 1/2 inch ET – 402028

Electronic pressure test case for pressure tests with connection possibility of up to 5 external pressure or temperature sensors. – the test procedures are menu-guided and can be carried out with simple Data entry dialog – a freely programmable pressure test is included – optional test sequences for gas and water tightness tests e.g. according to DVGW, ÖVGW, EWE, Avacon, WEVG. – a subsequent addition of test sequences is possible easily – large, illuminated display, even in direct sunlight easy to read – Data entry and signature via touch display and foil keys – Stylus for the touch display included – Data memory for hundreds of measurements, depending on test sequence – Communication via Bluetooth for update, data transmission, printer – LTE / GPS module (optional) – robust case (IP 67) – Operating time approx. 200 hours, extension with power supply possible from outside Dimensions: 220 x 90 x 168 mm Weight: approx. 1450 g

Test pump MPP 28-25 Pressure range 0 – 25 bar – practice-oriented test pumps with electronic control unit for the simplified performance of compression tests pursuant to EN 805 (W 400-2 in Germany) – automatic pressure stabilisation for preset test pressure which can be programmed in steps of 0.1 bar into the control unit – high delivery capacity rate of 28 l/min enable the generation of the required test pressure in less than 10 minutes, as required by the contraction procedure technical data: – connection value: 230 V / 400 V 50 Hz – power consumption: 2.200 VA – protection type: IP 54 – max. test pressure 25 bar – test pressure: 0 to 25 bar in steps of 0.1 bar – safety: safety valve – delivery volume: 28 l/min – decompression: automatic / manual – GSM-remote monitoring: optional

Test pump MPP 68-25 Pressure range 0 – 25 bar – practice-oriented test pumps with electronic control unit for the simplified performance of compression tests pursuant to EN 805 (W 400-2 in Germany) – automatic pressure stabilisation for preset test pressure which can be programmed in steps of 0.1 bar into the control unit – high delivery capacity rate of 68 l/min enable the generation of the required test pressure in less than 10 minutes, as required by the contraction procedure technical data: – connection value: 400 V 50 Hz – power consumption: 4.000 VA – protection type: IP 54 – max. test pressure 25 bar – test pressure: 0 to 25 bar in steps of 0.1 bar – safety: safety valve – delivery volume: 68 l/min – decompression: automatic / manual – GSM-remote monitoring: optional

Test pump MPP 68-35 Pressure range 0 – 35 bar – practice-oriented test pumps with electronic control unit for the simplified performance of compression tests pursuant to EN 805 (W 400-2 in Germany) – automatic pressure stabilisation for preset test pressure which can be programmed in steps of 0.1 bar into the control unit – high delivery capacity rate of 68 l/min enable the generation of the required test pressure in less than 10 minutes, as required by the contraction procedure technical data: – connection value: 400 V 50 Hz – power consumption: 5.000 VA – protection type: IP 54 – max. test pressure 35 bar – test pressure: 0 to 35 bar in steps of 0.1 bar – safety: safety valve – delivery volume: 68 l/min – decompression: automatic / manual – GSM-remote monitoring: optional

Test pump MPP 11 Pressure range 0 – 25 bar full automatic testing pump for pressure build-up and pressure holding adjusted without pressure impulses technical data: – connection value: 230 V 50 Hz – power consumption: 1.850 VA – protection type: IP 54 – max. test pressure 25 bar – test pressure: 0 to 25 bar in steps of 0.1 bar – safety: safety valve – delivery volume: 11 l/min. Maximum output approx. 300 l until automatic switch off, limited by temperature. – decompression: manual – Geka connection for water connection – quick coupling for pressure-side connection

Test head (stainless steel) with 4 plugs for pressure instrument, manual pressure gauge, electric waterpump and water flowmeter

P max: 60 bar and equipped with quick couplings and protective caps. In contrast to the HEINZ specimen, this specimen has two ball valves with quick couplings 5010 and one quick coupling 2510 without ball valve. A screw coupling -VA- is provided for connecting an external pressure sensor of the smart memo.
