Piston hammering lance for pin holes – 391006

Gas detection device for easily locating even the smallest leaks in water and heating systems – special, highly sensitive hydrogen sensor with a resolution of 0,1 ppm H2 – extremely fast reaction to the smallest traces of hydrogen – second sensor for pinpoint localisation in probe holes – integrated pump with high power for flow and for negative pressure Operation time: > 10 hours without lighting Measuring ranges: 0 to 1000 ppm H2 0 to 5 Vol.% H2 in N2 dimensions: 200 x 100 x 87 mm weight: approx. 1100 g temperature range: -10°C to +50°C

methane/propane and toxic gases Detect – Warn – Measure Rugged, explosion proofed measurement instrument with internal membranpump and reachargeable NiMH- battery. operating time: depending on application and backlight Application in accordance with DVGW G 465-4: – Enclosed space testing – Above ground inspection – Confined space entry – Building inspection – Bar hole testing – Purging gas purity Measurement ranges: – methane ppm, LEL, Vol.% – carbon dioxide 0 – 5 Vol.% / 0 – 100 Vol.% CO2 – propane ppm, LEL, Vol.% (optional) – oxygen 0 – 25 Vol.% O2 (optional) – carbon monoxide 0 – 500 ppm CO (optional) – hydrogen sulphide 0 – 100 ppm H2S (optional) – pressure measurement 0 – 2.000 hPa (optional) – flow speed measurement (optional) Dimensions: 200 x 100 x 87 mm Weight: approx. 1250 g Explosion proofed instrument: Sign: II 2G Ex ib d IIB T3/T4 Gb BVS 09 ATEX E 079 X Temperature range: -10°C <= Ta <= +40°C

methane and toxic gases Detect – Warn – Measure – Analyse Rugged, explosion proofed measurement instrument with internal membranpump and reachargeable NiMH- battery. Operating time: depending on application and backlight Application in accordance with DVGW G 465-4: – Enclosed space testing – Above ground inspection – Confined space entry – Building inspection – Bar hole testing – Purging gas purity – Ethane analysis Measurement ranges: – methane ppm, LEL, Vol.% – carbon dioxide 0 – 5 Vol.% / 0 – 100 Vol.% CO2 – oxygen 0 – 25 Vol.% O2 (optional) – carbon monoxide 0 – 500 ppm CO (optional) – hydrogen sulphide 0 – 100 ppm H2S (optional) – pressure measurement 0 – 2.000 hPa (optional) Dimensions: 200 x 100 x 87 mm Weight: approx. 1250 g Explosion proofed instrument: Sign: II 2G Ex ib d IIB T3/T4 Gb BVS 09 ATEX E 079 X Temperature range: -10°C <= Ta <= +40°C

GOLIATH RN without Ethane analysis methane/propane and toxic gases Detect – Measure Rugged, explosion proofed measurement instrument with internal membranpump and reachargeable NiMH- battery. Operating time: depending on application and backlight Application in accordance with DVGW G 465-4: – Enclosed space testing – Above ground inspection – Building inspection – Bar hole testing – Purging gas purity Measurement ranges: – methane ppm, Vol.% – carbon dioxide 0 – 5 Vol.% / 0 – 100 Vol.% CO2 – propane ppm, Vol.% (optional) – oxygen 0 – 25 Vol.% O2 (optional) – carbon monoxide 0 – 500 ppm CO (optional) – flow speed measurement (optional) Dimensions: 200 x 100 x 87 mm Weight: approx. 1250 g Explosion proofed instrument: Sign: II 2G Ex ib d IIB T3/T4 Gb BVS 09 ATEX E 079 X Temperature range: -10°C <= Ta <= +40°C

GOLIATH RN with Ethane analysis methane and toxic gases Detect – Measure – Analyse Rugged, explosion proofed measurement instrument with internal membranpump and reachargeable NiMH- battery. Operating time: depending on application and backlight Application in accordance with DVGW G 465-4: – Enclosed space testing – Above ground inspection – Building inspection – Bar hole testing – Purging gas purity – Ethane analysis Measurement ranges: – methane ppm, Vol.% – carbon dioxide 0 – 5 Vol.% / 0 – 100 Vol.% CO2 – oxygen 0 – 25 Vol.% O2 (optional) – carbon monoxide 0 – 500 ppm CO (optional) Dimensions: 200 x 100 x 87 mm Weight: approx. 1250 g Explosion proofed instrument: Sign: II 2G Ex ib d IIB T3/T4 Gb BVS 09 ATEX E 079 X Temperature range: -10°C <= Ta <= +40°C

GOLIATH RB methane/propane and toxic gases Warn – Measure Rugged, explosion proofed measurement instrument with internal membranpump and reachargeable NiMH- battery. operating time: depending on application and backlight Application in accordance with DVGW G 465-4: – Confined space entry – Bar hole testing – Purging gas purity Measurement ranges: – methane LEL, Vol.% – carbon dioxide 0 – 5 Vol.% / 0 – 20 Vol.% CO2 – propane LEL, Vol.% (optional) – oxygen 0 – 25 Vol.% O2 (optional) – carbon monoxide 0 – 500 ppm CO (optional) – hydrogen sulphide 0 – 100 ppm H2S (optional) – flow speed measurement (optional) Dimensions: 200 x 100 x 87 mm Weight: approx. 1250 g Explosion proofed instrument: Sign: II 2G Ex ib d IIB T3/T4 Gb BVS 09 ATEX E 079 X Temperature range: -10°C <= Ta <= +40°C

GOLIATH Localisation LOC methane/propane and toxic gases Measure Rugged, explosion proofed measurement instrument with internal membranpump and reachargeable NiMH- battery. Operating time: depending on application and backlight Application in accordance with DVGW G 465-4: – Purging gas purity – Bar hole testing Measurement ranges: – methane Vol.% – carbon dioxide 0 – 5 Vol.% / 0 – 20 Vol.% CO2 – propane Vol.% (optional) – oxygen 0 – 25 Vol.% O2 (optional) Dimensions: 200 x 100 x 87 mm weight: approx. 1250 g Explosion proofed instrument: Sign: II 2G Ex ib d IIB T3/T4 Gb BVS 09 ATEX E 079 X Temperature range: -10°C <= Ta <= +40°C
